Resolution |
8 dots/mm (203 DPI) |
Printing method |
Thermal Transfer & Direct Thermal |
Max. print speed |
152.4 mm (6")/second |
Max. print width |
108 mm (4.25") |
Max. print length |
25,400 mm (1000") |
Enclosure |
ABS plastic |
Physical dimension |
204 mm (W) x 164 mm (H) x 280 mm (D) 8.03" (W) x 6.46" (H) x 11.02" (D) |
Weight |
2.5 kg (5.51 lbs) |
Label roll capacity |
127 mm (5") OD |
Ribbon |
300 m long, max. OD 67 mm, 1" core (ink coated outside) 110 m long, max. OD 40 mm, 0.5" core
(ink coated outside) |
Ribbon width |
40 mm ~ 110 mm (1.6" ~ 4.3") |
Processor |
32-bit RISC CPU |
Memory |
• 128 MB Flash memory • 64 MB SDRAM |
Interface |
• USB 2.0 • Internal Ethernet, 10/100 Mbps • RS232 • USB host, for scanner or PC keyboard
• Internal Bluetooth 4.0 (factory option) • External Bluetooth (user option) |
Power |
External universal switching power supply
• Input: AC 100-240V, 2.5A, 50-60Hz
• Output: DC 24V, 2.5A, 60W |
Operation switch, button LED |
1 power switch, 1 feed and pause button & 1 LED (3 colors: green, amber & red) |
Sensors |
• Transmissive gap sensor • Black mark reflective sensor (position adjustable)
• Ribbon end sensor • Head open sensor |
Real Time Clock |
Standard |
Buzzer |
Standard |
Internal fonts |
• 8 alpha-numeric bitmap fonts • Monotype Image® true type font engine with one CG Triumvirate
Bold Condensed scalable font |
Bar code |
• 1D bar code
Code 128UCC, Code 128 subsets A, B, C, EAN128, Interleaved 2 of 5, Interleaved 2 of 5 with check digit,
Code 39, Code 39 with check digit, Code 93, EAN13, EAN8, UPCA, UPCE, EAN and UPC 2 (5) digits add-on,
Codabar, Postnet, MSI, MSI with check digit, PLESSEY, China post, ITF14, Code 11, TELEPEN, TELEPENN,
PLANET, Code49, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS
• 2D bar code
GS1 DataBar, GS1 DataMatrix, Maxicode, AZTEC, PDF417, QR Code, Micro PDF 417 |
Font and barcode rotation |
0, 90, 180, 270 degree |
Printer language |
TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL) |
Media type |
Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
Media width |
20 ~ 112 mm (0.8" ~ 4.4") |
Media thickness |
0.06 ~ 0.19 mm (2.36 ~ 7.48 mil) |
Media core diameter |
25.4 ~ 38 mm (1" ~ 1.5") |
Label length |
5 ~ 25,400 mm (0.2" ~ 1000") |
Environment condition |
Operation: 5 ~ 40°C, 25 ~ 85% non-condensing Storage: -40 ~ 60°C, 10 ~ 90% non-condensing |
Safety regulation |
FCC Class B, CE Class B, C-Tick Class B, UL, cUL, TÜV/safety, CCC, EAC, CoC, BIS, KC,
Energy Star |
Environmental concern |
Comply with RoHS, REACH, WEEE |
Accessories |
• Windows labeling software CD disk
• Quick start guide
• USB cable
• Power cord
• External universal switching power supply
• 1" label spindle, fixing tab x 2, 1.5" adapter x 2
• 1" ribbon spindle x 2 for 300M ribbon
• 1" ribbon paper core |
Limited warranty |
• Printer: 2 years
• Print head: 25 km (1 million inches) or 12 months which comes first
• Platen: 50 km (2 million inches) or 12 months which comes first |
Factory options |
Internal Bluetooth 4.0 |
Dealer options |
• Peel-off module • Guillotine cutter (full cut and partial cut) |
User options |
• External roll mount, media OD. 214 mm(8.4") with 76.2 mm (3") core
• External Bluetooth module (serial interface)
• KP-200 Plus keyboard display unit
• KU-007 Plus programmable smart keyboard |
