domipos Android POS
PM - 138
PM - 138
- 13.3-inch full HD touch main display with Android/Windows system
- Can install or develop various commercial POS software and other App
- 7.0-inch Android system display(optional), dual screen display, can be used to display cash register
information and user advertisements
- Outstanding ability to expand, external bar code gun, cash box, keyboard, mouse, printer and other
equipments
features
- Support magnetic stripe card, IC card, NFC/RFID card reading function(optional)
- Consistent with the host style 80mm thermal micro-dial, sharing a power adapter with the
host(optional)
specification
Main Screen |
|
Window 10 |
Android |
CPU |
Intel X5-Z8350, Speed 1.44 GHz Up To 1.92GHz, Quad – core |
Speed 2.0GHz, Quad-core |
Memory (SRAM) |
4G Bytes |
2G Bytes |
Storage (Nan flash) |
32G bytes |
8G Bytes (Can upgrade to 16G) |
Display screen |
13.3-inch color wide angle TFT screen, Resolution: 1920x1080 pixel |
Touch screen |
5 point touch capacitance touch screen |
Extended storage |
TF Card (Micro SD) Maximum support for 32 GB |
Rear screen (optional) |
CPU |
Speed 1.2GHz, Quad-core |
Memory (RAM) |
1G Bytes |
Storage (Nan flash) |
4G Bytes |
Display screen |
7-inch color IPS Screen, Resolution: 1024x600 pixel |
Touch screen |
5 point touch capacitance touch screen |
Operating system |
Android |
Camera |
5 million pixels (QR code scanning) |
Software updating |
support |
Printer |
80mm high speed thermal printing (optional) |
Printer power supply |
The power supply by the host |
Wireless communication |
Standard: Wi-Fi, Bluetooth (2.1&4.0) Mobile communication 2G/3G/4G (optional) |
Ethernet |
10/100m RJ-45 |
Interface |
Android Main Screen: 5 USB 2.0(Host) / Windows Main Screen: 4 USB 2.0 (Host), 1 USB 3.0
(Host), 1 RJ-45 Ethernet interface, 1 RJ-11 cash drawer interface, 1 printer interfaces
(power + USB), 1 power input ports |
Card reader |
Optional: Magnetic stripe card, IC card and NFC/RFID and module |
Peripheral accessories |
Optional: QR code scanner, Cash box, mPOS, Keyboard Kit |
Power supply(AC adapter) Input |
Voltage range: 100 ~ 240 v (AC) Frequency: 50Hz/60Hz |
Power supply(AC adapter) Output |
Input voltage: 24 V (DC) Current: 2.5 A |
Power input Parameters |
Input voltage: 24 V (DC) Current: 2.5 A (Warning: Please use the original AC adapter only.
Manufacturers have no responsibilities for the problems which are led by using unauthorized AC
adapter.) |
Physical dimensions Weight |
Host machine- 327.5mm(Width)x239mm (Depth)x234.5mm(Height)
Printer- 157mm(Width)x215mm (Depth)x145mm(Height)
Approx. Host machine- 2.4kg Printer- 1.6kg |
Environmental conditions |
Operating environment |
Temperature: 5 ~ 350C Humidity: 25 ~ 80% RH (No condensation) |
Storage environment |
Temperature: -40 ~ 550C Humidity: ≤93%RH (400C, No condensation) |
